VPL-FHZ700L 7,000 lumens WUXGA 3LCD Laser projector (Lens Not Included)

VPL-FHZ700L 7,000 lumens WUXGA 3LCD Laser projector (Lens Not Included)

Call for Price

The VPL-FHZ700L combines exceptional picture quality and brightness with the reliability, extended operating life and reduced running costs of laser projection.
Delivering crisp, brighter images with a class-leading 7,000 lumens brightness, the VPL-FHZ700L features a powerful, highly efficient laser light source that offers a nominal 20,000* hours operating time.

SKU: KSS-VPL-FHZ700L Categories: , Tags: ,

Description

The world’s brightest* 3LCD projector comes with a long-lasting laser light source, and offers high WUXGA image quality, versatile installation options and lowered running costs.

The VPL-FHZ700L combines exceptional picture quality and brightness with the reliability, extended operating life and reduced running costs of laser projection.

Delivering crisp, brighter images with a class-leading 7,000 lumens brightness, the VPL-FHZ700L features a powerful, highly efficient laser light source that offers a nominal 20,000* hours operating time.

With no waiting time for lamps to warm up or cool down, switching on/off is virtually instantaneous. Together with the long-life 3LCD panel and advanced filter system, the laser light source cuts the need for regular maintenance visits. There’s also a range of energy-saving features that contribute to a reduction in lifetime ownership costs compared with conventional projectors.

Its high brightness and minimal maintenance needs make the VPL-FHZ700L a compelling presentation choice in a wide range of applications – from boardrooms and lecture theatres to museums, exhibitions and retail spaces.

Installer-friendly features like free-angle installation and edge blending also assist with integration into a wide range of corporate, educational, public sector and entertainment environments.

*1 As of March 2014
*2 With Auto Light Dimming feature enabled. Actual hours may vary depending on usage.

Specification

  • Display System
    Display System     3 LCD system
  • Display device
    Size of effective display area  : 0.95” (24.1 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
    Number of pixels  : 6,912,000 (1920 x 1200 x 3) pixels
  • Projection lens
    Focus : Powered / Manual (Depend on lens)
    Zoom – Powered/Manual   :   Powered / Manual (Depend on lens)
    Lens shift – Powered/Manual : Powered / Manual (Depend on lens)
  • Light source
    Type   :  Laser Diode
  • Filter cleaning / replacement cycle (Max.)*1
    Filter cleaning / replacement cycle (Max.)   : 20000 H (cleaning)
  • Screen size
    Screen size  :   40” to 600” (1.02 m to 15.24 m) (measured diagonally)(Depend on lens)
  • Light output
    Lamp mode: High     7000lm
    Lamp mode: Standard     5600 lm
  • Color light output
    Lamp mode: High     7000 lm
    Lamp mode: Standard     5600 lm
  • Contrast ratio (full white / full black)*2
    Contrast ratio (full white / full black)     8000:1
  • Displayable scanning frequency
    Horizontal     14 kHz to 93 kHz
    Vertical     47 Hz to 93 Hz
  • Display resolution
    Computer signal input  : Maximum display resolution: WUXGA 1920 x 1200 dots
    Video signal input  : NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, 1080/24p
  • Color system
    Color system   :  NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
  • Keystone correction (Max.)
    Vertical :   +/-30 degrees
    Horizontal :   +/-30 degrees
  • OSD Language
    OSD Language : 24-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Farsi, Finnish, Indonesian, Hungarian, Greek)
  • INPUT OUTPUT (Computer/Video/Control)
    INPUT A   : RGB / Y PB PR input connector:Mini D-sub 15 pin (female)
    INPUT B   : RGB input connector: Mini D-sub 15-pin (female)
    INPUT C    : DVI-D input connector: DVI-D 24-pin (Single link), supported HDCP
    INPUT D   : HDMI input connector: HDMI 19-pin, HDCP support
    INPUT E   : Optional adaptor slot (For Digital Interface Adaptor BKM-PJ10)*4
    S-VIDEO IN : S-video input connector: Mini DIN 4-pin
    VIDEO IN   : Video input connector: BNC
    OUTPUT  :   Monitor output connector*5: Mini D-sub 15-pin (female)
    REMOTE  :   D-sub 9-pin (male) / RS232C
    LAN  :   RJ-45, 10BASE-T/100BASE-TX
    IR (Control S) : Control S input connector: Stereo mini jack, Plug in power DC 5V
    Control S output connector: Stereo mini jack
  • Acoustic noise
    Lamp mode: Low     33 dB
  • Operating temperature / Operating humidity
    Operating temperature / Operating humidity     0°C to 40°C (32°F to 104°F) / 35% to 85% (no condensation)
  • Storage temperature / Storage humidity
    Storage temperature / Storage humidity     -10°C to +60°C (-14°F to +140°F) / 20% to 80% (no condensation)
  • Power requirements
    Power requirements     AC 100 V to 240 V, 5.0A to 2.1 A, 50 Hz / 60 Hz
  • Power consumption
    AC 100 V to 120 V   :  Lamp mode: High: 497W
    AC 220 V to 240 V   :  Lamp mode: High: 476W
  • Power Consumption (Standby Mode)
    AC 100 V to 120 V   :  0.1 W (when “Standby mode” is set to “Low”)
    AC 220 V to 240 V  : 0.5 W (when “Standby mode” is set to “Low”)
  • Power Consumption (Networked Standby Mode)
    AC 100 V to 120 V   : 12.2 W (LAN), 13.8 W (HDBaseT), 13.8 W (All Terminals and Networks Connected) (when “Standby Mode” is set to “Standard”)
    AC 220 V to 240 V  : 8.4 W (LAN), 10.0 W (HDBaseT), 10.0 W (All Terminals and Networks Connected) (when “Standby Mode” is set to “Standard”)
  • Standby Mode / Networked Standby Mode Activated
    Standby Mode / Networked Standaby Mode Activated : After about 2 minutes
  • Dimensions (W x H x D)
    Approx. 530 x 204 x 545 mm (20 7/8 x 8 1/32 x 21 15/32 inches)
  • Mass
    Mass  :   Approx. 22 kg (47 lb)
  • Supplied accessories
    RM-PJ27 Remote Commander (1), Lithium battery: CR2025 (1), AC Power Cord (1), Operating Instructions (CD-ROM) (1), Quick Reference Manual (1)
  • Optional Accessories
    VPLL-4008/Z4011/Z4015/Z4019/Z4025/Z4045/Z4007/ZM42/FM22/ZM102
    PK-F500LA1, PK-F500LA2

Additional information

Weight 25 kg
Dimensions 54.5 x 53 x 20.4 cm
Brand

Projection System

Color

White

Native Resolution

Contrast Ratio

Aspect Ratio

Image-Size (Diagonal)

Brightness (ANSI Lumens)

Build-in Speaker

No

Warranty

3
